Difference Between Physical Foaming and Chemical Foaming


Aug . 2023
Foam, with its unique structure and versatile properties, can be crafted using various methodologies, primarily bifurcated into two dominant techniques: physical and chemical foaming. Though both aim to introduce air bubbles or pockets into materials, the mechanisms and intricacies behind each process are markedly different.

Physical foaming

Physical foaming is the use of physical principles of foaming, such as the plastic dissolved into a gas or liquid, and then make it expand or vaporize.

Process: In this method, a physical blowing agent (often a gas like nitrogen or carbon dioxide) is introduced into the polymer matrix. When the polymer is subsequently heated, the blowing agent vaporizes or expands, creating bubbles or foam in the polymer.

Advantages: It does not involve any chemical reaction, so there's no residue or unwanted byproducts. It can also lead to a more consistent cell structure in the foam.

Chemical foaming

Chemical foaming is the use of specially added chemical foaming agent heated decomposition or chemical reaction between raw material components to produce gas, so that plastic melt filled with bubble hole method.

Process: Chemical foaming agents (CFAs) are added to the polymer. Upon heating, these CFAs decompose and release gases like nitrogen, carbon dioxide, or water vapor. This gas generation results in the formation of foam or bubbles within the polymer.

Advantages: The foam structure can be adjusted by varying the type and amount of CFA used. This method can produce high expansion ratios and can be used for a wide range of polymers.

The requirements of physical foaming agent are low boiling point material, non-toxic, odorless, no corrosion, no combustion, good thermal stability, no chemical reaction under the gas phase, and small diffusion coefficient in the plastic melt in the gas phase. supercritical

Physical foaming molding (supercritical)

Supercritical foam molding is a kind of physical foam molding technology, but also a kind of microcellular foam molding technology, it is in the injection molding, extrusion and blow molding process, the supercritical state of carbon dioxide or nitrogen and other gases into a special plasticizing device, so that the gas and molten raw materials are fully and evenly mixed/diffused to form single-phase mixed sol. Then the sol into the mold cavity or extrusion die, so that the sol produce a large pressure drop, so that the gas precipitated to form a large number of bubble nuclei; In the subsequent cooling molding process, the bubble nuclei inside the sol continue to grow and form, and finally obtain microcellular foaming plastic products.

Faninger, an early foaming production pioneer in China, has excellently merged industrial design with scientific innovation through its development of the supercritical foaming extrusion experimental line. This state-of-the-art line has been instrumental in offering valuable production insights and advanced equipment technology to universities, research institutes, and enterprises. Furthermore, Feininger stands out as China's premier professional manufacturer of XPS Extrusion Line and XPS Foam Board. This dual expertise underscores their unique position in the market, not just in the realm of XPS Foam production but also in the development, manufacturing, and sales of XPS equipment.
